Ručni električni viljuškar 2,2 - 2,5t

122 mm
2000 - 2500 kg

Level adjustment due to ramp lift
Powerful 3-Phase AC technology for maximum performance
Especially robust chassis for high stress
Up-to-date control unit electronic for perfect handling
Excellent energy management for low operation costs

EJE 220r/ 225r

The robust and powerful electric pallet trucks EJE 2 are equipped with our patented ramp lift that makes loading and unloading a HGV at a ramp even more efficient. The ramp lift works independently from the regular lift and enables a levelling of ramps with gradients of up to 15 percent. For even faster loading and unloading. Innovative control units allow for a safe and easy handling. Therefore, our tiller head is packed with innovative technologies and is perfectly adjusted for the operator. Our intuitive colour coding and button system, for example, allow for fatigue-free operations and maximum safety. Our focus on durability shows in every detail: The EJE series with ramp lifts do not only have a robust steel chassis and reinforced forks but also non-contact sensors in the tiller head for highest reliability. This guarantees highest reliability.

Litijum-jon

JUNGHEINRICH LITIJUM-JONSKA TEHNOLOGIJA

Litijum-jon

Litijum-jonska snaga kompanije Jungheinrich Vam omogućava da budete daleko ispred konkurencije.

SAZNAJTE VIŠE

Prednosti

Povezani viljuškari

Koristite podatke sa svojih viljuškara da uštedite vreme, energiju i novac i povećate efikasnost. Naša telematička kutija Vam pruža besplatan početni paket za upravljanje voznim parkom koji se može fleksibilno proširiti različitim hardverskim i softverskim komponentama.

Karakteristike

Efficient 3-phase AC technology

High efficiency levels with excellent energy management.
Strong acceleration even at maximum load.
Fast change of direction without delay.
No carbon brushes – maintenance-free drive motor.
2-year warranty on driving motor.

Professional battery management

Batteries with up to 375 Ah allow for long operating times.
Short version: 2 PzS 180 Ah/250 Ah.
Long version: 3 PzS 375 Ah.
Built-in charger (24 V/30 A for wet cell batteries and maintenance-free-batteries) allows easy recharging of the battery at any power outlet (optional).
Lateral battery change for multi-shift applications (optional).

Available with lithium-ion technology

High degree of availability thanks to extremely short charging times.
No battery exchange required.
Saving costs due to longer service life and zero maintenance as compared to lead-acid batteries.
No charging rooms and ventilation required as there is no build up of gas.

Robust design for toughest applications

8 mm high-grade steel apron on the front of the frame.
High residual capacities due to reinforced fork construction.
2-year warranty on driving motor.
Fast acceleration.

Optimum cornering

Sprung and cushioned support wheels – linked via the ProTracLink torsion bar – distribute equalising forces dependent on travel conditions.
Perfect for loading and unloading HGV as well as the work on ramps.
Evenly over all wheels during straight-line travel.
Concentrated on the outer support wheel when cornering.

Lower maintenance costs

Maintenance-free 3-phase AC drive motor without carbon brushes.
Easy access to all components through one-piece front cover secured by only two screws.
Excellent protection against dust and humidity through IP 54 enclosure of controller and plugs.
Reduced support wheel wear when approaching ramps at an angle thanks to level equalisation.

Level adjustment due to ramp lift

In addition to the normal lift, the trucks are fitted with a patented ramp lift for gradients of up 15 %.
The ramp lift operates separately from the normal lift, thus the first pallet row in HGVs can also easily be loaded and unloaded.

Ergonomic tiller head

A clear colour coding system and buttons with abrasion resistant symbols for intuitive operation.
Grip angle to suit the hand position of the operator.
Crawl speed button underneath the tiller arm for easy access and travelling with the tiller upright.
Rocker switch for consistently good operation in all tiller positions.
The tiller also has excellent protection against breakdown with contactless sensor technology, protected according to IP 65.
